PBS-500/600/800/1000 Plastic PVC SPC WPC grinding milling machine for sheet board profiles

Brand Name : BEISU

Model Number : PBS-800

Certification : CE

Place of Origin : China

MOQ : 1 Set

Price : USD13000

Payment Terms : L/C, T/T,

Supply Ability : 150 Sets per year

Delivery Time : 25 working days

Packaging Details : Plastic film packing and pallet fixed on the machine bottom

Application : PVC SPC WPC

Model : PBS-800

Heating mixermotor power : 75Kw

Inverter brand : Delta

Temperature control brand : OMRON

Paddle mode : 72 Pcs

Capacity : 800Kg/h

Contact Now

PBS-500/600/800/1000 Plastic PVC SPC WPC grinding milling machine for sheet board profiles


PVC SPC WPC crusher and miller machine are mainly used to crush SPC and PVC waste materials directly and grind them into powder; such as PVC stone plastic wallboard, stone plastic door panel, PVC gusset plate, LVT floor, furniture board, PVC film, PVC edge banding strip, SPC floor, plastic door and window. No need to cut the material. Continuous feeding is possible. It is mainly used for recycling waste boards, sheets and profiles of hard PVC and SPC.


Technical features of PBS crushing milling machine:

A1: Adopting a special long oblique bucket design; ensuring that boards, gusset plates, floors, door panels and profiles can be fed continuously at one time without cutting. The feed port is large and the crushing chamber is high, which is suitable for hardness and agglomeration materials.
A2. Mobile screen, the mesh size can be customized as needed

A3. The feed port is equipped with a protective curtain to protect the safety of operators

A4. The machine is sturdy, shockproof, stable and has high production efficiency. ”



Technical date:


1 Model PBS-800
2 Moving blade quantity 72
3 Blade dimension mm 160×60×6
4 Motor power KW 75
5 Thickness of mesh mm 6
6 Diameter of mesh mm 6
7 Capacity Kg/h 600-700
8 Rotary diameter mm 650
9 Driving method   Motor directly connect
10 Voltage   380V 50Hz Can be customized according to the requirements
11 Bearing quantity PCS 2
12 Beating brand   NSK
13 Discharge method   Fan blower
14 Suction blower motor power Kw 7.5
15 Motor brand   China
16 Start and off   Star-delta starting


PBS-500/600/800/1000 Plastic PVC SPC WPC grinding milling machine for sheet board profilesPBS-500/600/800/1000 Plastic PVC SPC WPC grinding milling machine for sheet board profiles

PBS-500/600/800/1000 Plastic PVC SPC WPC grinding milling machine for sheet board profiles
PBS-500/600/800/1000 Plastic PVC SPC WPC grinding milling machine for sheet board profilesPBS-500/600/800/1000 Plastic PVC SPC WPC grinding milling machine for sheet board profiles
PBS-500/600/800/1000 Plastic PVC SPC WPC grinding milling machine for sheet board profiles
PBS-500/600/800/1000 Plastic PVC SPC WPC grinding milling machine for sheet board profiles

PBS-500/600/800/1000 Plastic PVC SPC WPC grinding milling machine for sheet board profiles

PBS-500/600/800/1000 Plastic PVC SPC WPC grinding milling machine for sheet board profiles

PBS-500/600/800/1000 Plastic PVC SPC WPC grinding milling machine for sheet board profiles

PBS-500/600/800/1000 Plastic PVC SPC WPC grinding milling machine for sheet board profiles





PBS-500/600/800/1000 Plastic PVC SPC WPC grinding milling machine for sheet board profiles

PBS-500/600/800/1000 Plastic PVC SPC WPC grinding milling machine for sheet board profiles

PBS-500/600/800/1000 Plastic PVC SPC WPC grinding milling machine for sheet board profiles

PBS-500/600/800/1000 Plastic PVC SPC WPC grinding milling machine for sheet board profiles

PBS-500/600/800/1000 Plastic PVC SPC WPC grinding milling machine for sheet board profiles

PBS-500/600/800/1000 Plastic PVC SPC WPC grinding milling machine for sheet board profiles

PBS-500/600/800/1000 Plastic PVC SPC WPC grinding milling machine for sheet board profiles



PBS-500/600/800/1000 Plastic PVC SPC WPC grinding milling machine for sheet board profiles

Zhangjiagang Beisu Machinery Co,Ltd is a certified manufacturer, exporter and supplier of
plastic PVC/PE/PP/PET/EVA/ABS processing machinery. Due to our constant commitment to
extrusion technology, we have emerged as a leading manufacturer of Plastic Extrusion
Machinery for PVC pipes Extrusion Line, HDPE pipes Extrusion Line, PVC compounding
Extruder, PPR Pipes Extrusion Line, PVC profiles Extrusion Line.
Especially High speed Plastic mixer, PVC compounding mixer, SPC mixer.WPC mixer,Plastic Granulating and Pelletizing Line,Plastic pvc pelletizing machine,Soft PVC shoes granulator, PVC compounding pelletizer and Plastic PVC pulverizer, PVC miller,SPC milling machine, WPC pulverizer, SPC pulverizer, PE pulverizer,LDPE pulverizer,PET pulverizer,ABS pulverizer,HDPE pulverizer,Plastic pulverizer, Plastic milling machine, Plastic miller machine,Plastic Crusher,PVC crusher,PE crusher,PP shredder, Plastic PVC Shredder etc for a wide range of extrusion processes.
Installation Instructions

1. Before shipment testing at factory, vedio record.
2. Vedio instruction for operation.
3. User manual and installation instruction, layout and drawings.
4. Lable&marks for disassemble parts, wiring&cables.

Our Advantages

1.Reliable

  • Most popular design with years' verification.

  • Mature supply chain for raw materials with strict quality assurance.

  • International famous brands of key parts i.e. ABB invertor, Siemens electronics, Siemens motor, Mettler Toledo scale etc.

2. Economy

  • BEISU Stable technology commercialized in China.

  • High efficiency mixing performance.

  • Cost effective solutions.

After Sales Service

Real time communication SNS group chat(WeChat preferred, Skype/WhatsApp) which includes buyer side and BEISU service team is created for technical assistance in the quickest manner. Scheduled video calls are also available. Just as the company vision 'Customer Oriented' says,BEISU always stands at customer's point to offer the optimum solution and help customer to maximize profit. BEISU has its own customer management system and spare parts management system which ensure quickest responds and enough regular easy-wearing parts whenever customer requests.
